Pilot-RC Laser 103IN 07 (Green/Black/White) PIL692
£1,389.95
Out of stock Product is not in our store or currently available from our supplier. The item can still be ordered but lead times will vary.
Description
Description
Pilot-RC Laser 103IN 07 (Green/Black/White) PIL692
The Laser has been fully designed from the ground up for out and out performance, keeping in line with current demand for faster, more aggressive and more agile models, while still keeping the well know great flying characteristics Pilot-RC models are known for.
You really need to see the videos of this model in action to understand its capability. In this case, its not a question of if the plane is quick enough, its whether you can keep up!
FEATURES
NEW! Full Carbon reinforced fuselage and wing using carbon laminated wood and carbon stringers.
Genuine German Oracover (Ultracote) covering
Highly prefabricated, experienced builders can have air ready in under a day
Pre-installed hinges (glued and pinned)
Internally mounted cowling – so no external screws exposed
Includes cooling baffles
Exhaust tunnel pre-installed in fuselage for easy canister installation
Removable rudder (as well as removable wings and stabs)
Laser engraved motor mounting position
Push-Pull system for Rudder servos
*Due to carbon construction, this kit does not offer Free replacement wood
INCLUDED HARDWARE
Complete air frame with all basic accessories (such as carbon fibre main undercarriage, tail-gear assembly and wing-tubes as well as fibreglass control horns and wheel pants)
Pre-installed hinges and pre-mounted canopy
Fuel tank and fuel tubing pre-prepared, fuel dot and breather valve
Wheels, axels and wheel pants
Pre-prepared pull-pull wires and pushrods with ball links
Matching carbon spinner
REQUIRED HARDWARE (NOT SUPPLIED)
Motor: 80-120cc or equivalent electric (Please note if your using a Saito FG-100TS 4-Stroke you will require a 26″x10″ prop)
Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox and possibly other small accessories.
SPECIFICATIONS
Model: Laser – 35%
Wingspan: 103in (2.610mm)
Length: 93.7in (2.380mm)
Wing area: 1,771sq in (11,430sq cm)
Weight: 27.5lbs (12.5kg)
BUILD INFORMATION
COWL SIZE
A: 335mm – B: 330mm – C: 307mm – D: 348mm
EXHAUST TUNNEL SIZE
A: 603mm – B: 103mm – C: Unlimited – D: 131mm – E: 172mm – F: 192mm
Due to the open tunnel design in the Laser, there is no backplate (measurement C) so there is no limit to the length of exhaust that can be used.
RUDDER HORNS AND PULL PULL LOCATION
A: 31mm – B: 55mm – C: 60mm – D: n/a – E: 8.5mm
SERVO EXTENSION LENGTHS
Throttle: 40cm
Each aileron: 25cm + 75cm (nearest servo and furthest servo – to reach receiver direct)
Each elevator: 150cm
Rudder: 140cm (when using direct – if installing pull pull, no required extension)
CENTRE OF GRAVITY
194mm – Measured back from leading edge of the wing at the fuselage.
You will find a laser engraved C.G. emblem on the inside of the fuselage, located close to the wing tube, which also shows the exact location for Center of Gravity.
For information on Local Clubs or news within the flying world BMFA, click the highlighted tabs.
Specification
Specification
| Power | Electric, Engine |
|---|---|
| Brand | Pilot RC |
| Assembly | ARTF & PNP |
| Aircraft Type | Sports & 3D |
